48V Counterbalance Forklift Truck Electronic Control Comfortable Design
  • name
  • name

48V Counterbalance Forklift Truck Electronic Control Comfortable Design

MOQ: 1 set
Price: Negotiable
Standard Packaging: Nude
Delivery Period: 25 - 30 days
Payment Method: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Capacity: 100 sets per month
Detail Information
Product Description
Detail Information
Place of Origin
Zhejiang, China
Brand Name
REACH
Certification
CE, TUV
Model Number
CQD15M
Capacity:
1500kg
Max. Lifting Height:
3000/5000/6200mm
Fork Dimensions:
35/100/1070mm
Aisle Width For Pallets 1000*1200 Crossways:
2800mm
Aisle Width For Pallets 800*1200 Lengthways:
2850mm
Travel Speed, Load/unload:
7/7.2km/h
Battery:
48V400AH
Highlight:

narrow aisle forklift truck

,

double reach forklift

,

48V Counterbalance Forklift Truck

Product Description

1500kg counterbalanced electric narrow aisle truck mast reach distance 600mm



Quick Details:

Product name: Counterbalanced electric narrow aisle truck CQD15M

Capacity: 1500kg​

Max. Lifting height: 3000/5000/6200mm​

​Fork dimension: 35/100/1070mm

​Travel speed, load/unload: 7/7.2km/h​​

Lift speed, load/unload: 0.19/0.2m/s

​Lowering speed, load/unload: 0.5/0.4m/s

​Aisle width for pallets 1000*1200 crossways: 2800mm

Aisle width for pallets 800*1200 lengthways: 2850mm

Battery: 48V400AH



Advantages:

  • ​​​The wide and strong forklift chassis ensures the sufficient stability of the forklift and the lifting height 3-6.2meters.

  • Using high quality imported Krupp mast to improve the service life and stability.

  • Spacious and comfortable cabin and adjustable seat, more embodies the humanized design of the narrow aisle truck.

  • High speed limit setting, when the forks lift up to a certain height, the narrow aisle truck speed will automatically decline, to ensure the safety of high-altitude operations.

  • With double electric control system, the lifting of goods and the driving of forklift can realize stepless speed change.

  • Full hydraulic power steering system makes the steering flexible and portable.

  • The braking of the driving motor is controlled by the electronic control system, so that the starting, driving and braking of the forklift are more effective.

  • There are two ways to install the battery: 1. side pull out, make the battery replacement more convenient. 2. the battery is pushed out and pulled in automatically with the mast, which is easy for daily maintenance.





SPECIFICATIONS
Model   CQD15M
Power   battery
Operate type   seated
Capacity/rated load kg 1500
Lifting height mm 3000/5000/6200
Load center distance mm 500
Drive wheel mm 280*100
Fork wheel mm 285*80
Tilt of mast/fork carriage forward/backward Grad 2,3(mast)/ ~ / ~
Height, mast lowered mm 2086/2240/2640
Free lift mm ~ /1700/2100
Height, mast extended mm 3800/5800/7000
Height of overhead guard(cabin) mm 2114
Seat height/stand height mm 920
Height of crura mm 270
Overall length mm 2390
Length(barring fork) mm 1850
Overall width mm 1100
Fork dimensions mm 35/100/1070
Reach distance mm 600
Aisle width for pallets 1000*1200 crossways mm 2800
Aisle width for pallets 800*1200 lengthways mm 2850
Turning radius mm 1740
Travel speed, laden/unladen km/h 7/7.2
Lift speed, laden/unladen m/s 0.19/0.2
Lowering speed, laden/unladen m/s 0.5/0.4
Battery V/Ah 48/400
Service weight kg 2400/2800/2900





48V Counterbalance Forklift Truck Electronic Control Comfortable Design 048V Counterbalance Forklift Truck Electronic Control Comfortable Design 1
